Features:
- All in One Panel Control: Unlimited number of control devices, supports control of all SONOFF devices, from smart lights, smart cameras, and security sensors to switches, etc. and will continue to support SONOFF’s new device in the future.
- Build-in Zigbee Hub: Quickly add Zigbee devices on the screen in batches. Standard Zigbee 3.0 protocol makes the connection more stable and the coverage wider. Added sub-devices can be voice-controlled by using Alexa, Google Home, and more.
- Home Security: Customize 3 modes by setting different arming devices. After arming, once the sensor is triggered, the panel will alarm, and you will receive a notification alert on the phone.
- Temp-Control: Choose the temperature source (e.g. TH Elite) and execution devices (e.g. MINIR4M, ZBMINIL2…) to create a thermostat / cooling / heating system and maintain a suitable room temperature .
- Camera Viewer: NSPanel Pro can be used as a display and supports adding different types of cameras for live monitoring.
Overview
NSPanel Pro is a smart scene control panel integrating a touch screen, Zigbee hub, and smart security features. You can control the devices by adding them as widgets on the panel, adding various Zigbee sub-devices through the built-in Zigbee gateway, setting security modes to guard your home, and viewing the live view on the panel through an added camera. Compatible with more brands, and with more practical functions such as power consumption statistics, thermostats, call intercom, etc.
NSPanel pro supports the control of all SONOFF devices, from smart lights, smart cameras, and security sensors to switches, etc., and will continue to support SONOFF’s new devices in the future.
NSPanel Pro 120 Type can be used as a Matter hub (Matter controller), allowing you to add Matter switches, sockets, sensors, and other devices from different manufacturers to the eWeLink APP for management and control. In addition, it also supports adding Matter bridges from different brands, thereby enhancing NSPanel Pro’s compatibility with third-party devices.
Zigbee devices can be added in batches on the NSPanel Pro . Standard Zigbee 3.0 protocol makes connections more stable and the offer wider coverage. Added sub-devices can be voice-controlled via Alexa, Google Home, and more. You can customize 3 modes by setting different arming devices. In armed state, the panel will sound the alarm when sensors are triggered and will send a notification alert to your phone. You can freely customize the home screen style or wallpaper of the NSPanel Pro, creating an attractive interface that makes daily use more convenient.
Temperature sources can be selected and other smart devices controlled to form your own thermostat and maintain a comfortable room temperature. The NSPanel Pro can be used to display a smart camera, allowing the viewer to monitor the situation from a safe distance. Two-way talk communication is also possible via the NSPanel Pro’s built-in microphone and speaker (which also supports mobile phone-to-panel, and panel-to-panel calls.
The SONOFF NSPanel Pro also offers alternative expansion options, e.g. partial-sync add-on, open API, home bridge, Node-RED. Additional functions are also avaialable such as power consumption, reminders, Pincode, clock, 7-day forecasts, and guest mode.
More updates and features will follow in the future. Choose the Sonoff NSPanel Pro for your smart Home needs.
Specifications:
- Zigbee: IEEE 802.15.4 (Zigbee 3.0)
- Wi-Fi: IEEE 802.11 b 2.4GHz
- Input: 100-240V AC 50/60Hz
- Max Power Consumption: 5W MAX; 150mA
- TFT Screen Size: 3.95″ (Capacitive Screen)
- Screen Resolution: 480 x 480
- MCU: PX30
- CPU: 4-cores Cortex-A35
- GPU: Mali-G31GPU
- RAM: 2GB, DDR3
- ROM: 8GB, eMMC 5.1
- Certifications: CE/UKCA/ SRRC/RoHS
- Shell Materials: PC V0+CRS+Toughened Glass
- Dimension: 86x86x39.5mm
NSPanel Pro supports devices list:
- Wi-Fi
- DIY Smart Switch: MINIR2, MINIR3, MINIR4, MINIR4M,BASICR2, BASICR3, BASICR4, RFR2, DUALR2, 4CHR3/4CHPROR3, TH10/TH16, TH Origin, TH Elite,POWR2, POWR3, POW Origin, POW Elite, Micro, Micro MFG, SlampherR2, DUALR3/ DUALR3 Lite,SPM-4Relay
- Smart Wall Switch: TX, TX Ultimate, M5, IW101/IW100
- Smart Lighting: D1, B02/B05-BL LED Bulb, LED Filament Bulb, Smart LED Bulb,L1, L1 Lite, L2, L2 Lite, L3, L3-P Home Security & Sensor CAM-Slim, GK-200MP2-B, DW2-Wi-Fi
- Central Control Panel: NSPanel
Smart Plug S26, S26R2, S55
- Zigbee
- DIY Smart Switch: ZBMINI, BASICZBR3, ZBMINI-L, ZBMINL2, SNZB-01,SNZB-01P
- Sensor: SNZB-02D, SNZB-02P,SNZB-02, SNZB-03, SNZB-04, SNZB-06P, SNZB-03P, SNZB-04P, SNZB-05P
- Home Appliance: ZBCurtain, TRV
- Smart Plug: S26R2ZB
- eWeLink-Remote
- DIY Smart Switch: S-MATE, S-MATE2
- Scene Controller: R5
The NSPanel Pro can be used with Home Assistant… Sync the devices from Home Assistant to the eWeLink App through the add-on, then add the Home Assistant’s devices to the panel by adding widgets.
What’s in the box:
- 1 * NSPanel Pro
- 1 * User Manual
Notes:
- More information is available on the Manufacturer’s product page.
- Sonoff NSPanel Pro variations require L and N wires.
- All SONOFF Zigbee devices and other brands using the standard Zigbee 3.0 protocol are supported. Philips Hue lights and IKEA lights will be supported in 1.2.0.
- NSPanel Pro can be used to access local Zigbee devices via iHost.
